HYBRID / BATTERY CONTROL  HV RELAY ASSEMBLY(for LITHIUM-ION BATTERY)  REMOVAL

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during HV battery junction block assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced

Replaced Part or Performed Procedure	Necessary Procedure	Effect/Inoperative Function when Necessary Procedure not Performed	Link
Replacement of HV battery junction block assembly	Current sensor offset learning	DTCs are stored	(202304,999999,_51,_080773,_0599560,RM100000002B8MP_01_0296,)
	High voltage fuse accumulated load history reset	DTCs are stored	8ZR-FXE:(202304,999999,_51,_080773,_0600293,RM100000002BC01,) M20F-FXS, M20G-FXS:(202307,999999,_51,_080773,_0615953,RM100000002CVG0,)

CAUTION:

·

Orange wire harnesses and connectors indicate high-voltage circuits. To prevent electric shock, always follow the procedure described in the repair manual.

Click hereGeneral>INTRODUCTION>REPAIR INSTRUCTION>PRECAUTION201906,999999,_V1,_080724,_0393249,RM100000001HWSK,

·

To prevent electric shock, wear insulated gloves when working on wire harnesses and components of the high voltage system.

NOTICE:

After turning the power switch off, waiting time may be required before disconnecting the cable from the negative (-) auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) auxiliary battery terminal notices before proceeding with work.

HINT:

When the cable is disconnected / reconnected to the auxiliary battery terminal, systems temporarily stop operating. However, each system has a function that completes learning the first time the system is used.

Learning completes when vehicle is driven

Effect/Inoperative Function when Necessary Procedure not Performed	Necessary Procedure	Link
Front Camera System	Drive the vehicle straight ahead at 15 km/h (9 mph) or more for 1 seconds or more.	(202304,999999,_95,_139716,_0584193,RM1000000029F4C,)
