TIRE PRESSURE MONITORING  TIRE PRESSURE WARNING RECEIVER  REMOVAL

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during tire pressure warning ECU and receiver removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced (for HV Model)

Replaced Part or Performed Procedure	Necessary Procedure	Effect/Inoperative Function when Necessary Procedure not Performed	Link
Tire pressure warning ECU and receiver	· ID Registration · Initialization · Tire Position Identification	Tire Pressure Warning System	(202304,999999,_53,_080780,_0393956,RM100000002AI0K,)

Necessary Procedures After Parts Removed/Installed/Replaced (for Gasoline Model)

Replaced Part or Performed Procedure	Necessary Procedure	Effect/Inoperative Function when Necessary Procedure not Performed	Link
Tire pressure warning ECU and receiver	for Type A · Register transmitter ID · Initialize tire pressure warning system	· When DTC detection conditions of "transmitter ID not received" DTC are met, TPWS indicator blinks for 1 minute, and then illuminates · Tire pressure warning function	(202304,999999,_53,_080780,_0393955,RM100000002B0BZ,)for Registration (202304,999999,_53,_080780,_0393955,RM100000002BB37,)for Initialization
	for Type B · ID Registration · Initialization · Tire Position Identification	Tire Pressure Warning System	(202304,999999,_53,_080780,_0592791,RM100000002AHTO,)

NOTICE:

When replacing the tire pressure warning ECU and receiver, read the transmitter IDs stored in the old ECU using the GTS and write them down before removal.

for HV Model: Click hereSuspension>TIRE PRESSURE MONITORING>TIRE PRESSURE WARNING SYSTEM (for HV Model)>DATA LIST / ACTIVE TEST202304,999999,_53,_080780,_0393956,RM100000002AI0X,

for Gasoline Model (for Type A): Click hereSuspension>TIRE PRESSURE MONITORING>TIRE PRESSURE WARNING SYSTEM (for Gasoline Model (for Type A))>DATA LIST / ACTIVE TEST202304,999999,_53,_080780,_0393955,RM100000002BB6G,

for Gasoline Model (for Type B): Click hereSuspension>TIRE PRESSURE MONITORING>TIRE PRESSURE WARNING SYSTEM (for Gasoline Model (for Type B))>DATA LIST / ACTIVE TEST202304,999999,_53,_080780,_0592791,RM100000002AHTY,
