PA10/PB10 HYBRID TRANSMISSION / TRANSAXLE  MOTOR CABLE  REMOVAL

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during motor cable removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced

Replaced Part or Performed Procedure	Necessary Procedure	Effect/Inoperative Function when Necessary Procedure not Performed	Link
Replacement of ECM	Vehicle Identification Number (VIN) or frame number registration	DTC stored	for 8ZR-FXE:(202304,999999,_51,_080778,_0393982,RM100000002BDLH,) for M20F-FXS, M20G-FXS:(202307,999999,_51,_146896,_0611112,RM100000002CI3X,)
	ECU configuration	-	(202304,999999,_V1,_143216,_0598316,RM100000002B3MK,)
	Update ECU security key	Vehicle Control History (RoB) are stored	(202304,999999,_V1,_143216,_0598316,RM100000002B3ML,)
	Perform Total Short Trip Estimate Registration	-	for 8ZR-FXE:(202304,999999,_51,_080778,_0393982,RM100000002BDLH,) for M20F-FXS, M20G-FXS:(202307,999999,_51,_146896,_0611112,RM100000002CI3X,)
Replacement of inverter with converter assembly	ECU configuration	-	(202304,999999,_V1,_143216,_0598316,RM100000002B3MK,)
	Resolver learning	· DTCs are stored · Slight vibration at a vehicle speed of 5 km/h (3 mph) or less · Shock or vibration during acceleration	for 8ZR-FXE:(202304,999999,_51,_080773,_0600292,RM100000002BBW3,) for M20F-FXS, M20G-FXS:(202307,999999,_51,_080773,_0615952,RM100000002CVBZ,)

CAUTION:

·

Orange wire harnesses and connectors indicate high-voltage circuits. To prevent electric shock, always follow the procedure described in the repair manual.

-

for 8ZR-FXE:

Click hereEngine / Hybrid System>HYBRID / BATTERY CONTROL>PA10 HYBRID CONTROL SYSTEM (for LITHIUM-ION BATTERY)>PRECAUTION202304,999999,_51,_080773,_0600291,RM100000002BBUE,

-

for M20F-FXS, M20G-FXS:

Click hereEngine / Hybrid System>HYBRID / BATTERY CONTROL>PB10 HYBRID CONTROL SYSTEM (for LITHIUM-ION BATTERY)>PRECAUTION202307,999999,_51,_080773,_0615951,RM100000002CVA9,

·

To prevent electric shock, wear insulated gloves when working on wire harnesses and components of the high voltage system.

·

To prevent burns, do not touch the engine, exhaust pipe or other high temperature components while the engine is hot.

HINT:

When the cable is disconnected / reconnected to the auxiliary battery terminal, systems temporarily stop operating. However, each system has a function that completes learning the first time the system is used.

Learning completes when vehicle is driven

Effect/Inoperative Function when Necessary Procedure not Performed	Necessary Procedure	Link
Front Camera System	Drive the vehicle straight ahead at 15 km/h (9 mph) or more for 1 second or more.	(202304,999999,_95,_139716,_0584193,RM1000000029F4C,)
