SEAT BELT REAR SEAT OUTER BELT ASSEMBLY(for Commuter, 4-Passenger Seat) REMOVAL
CAUTION / NOTICE / HINT
- CAUTION:
- ·
Wear protective gloves. Sharp areas on the parts may injure your hands.
·There is risk of injury.
- HINT:
- ·
Use the same procedure for RHD and LHD vehicles.
·The procedure listed below is for LHD vehicles.
PROCEDURE
1.REMOVE REAR SEAT ASSEMBLY LH
79967V
2.REMOVE REAR NO. 1 SEAT NO. 3 LEG SIDE COVER
79967T
3.REMOVE REAR NO. 1 SEAT NO. 1 LEG SIDE COVER
79967U
4.REMOVE REAR NO. 1 SEAT NO. 2 LEG SIDE COVER
71834J
5.REMOVE NO. 1 SEAT OUTER NO. 1 RECLINING COVER LH
73330G
6.REMOVE REAR SEAT LAP TYPE BELT ASSEMBLY LH
Remove the bolt and rear seat lap type belt assembly LH.
71833K
7.REMOVE NO. 1 SEAT OUTER NO. 1 RECLINING COVER RH
73380A
8.REMOVE REAR SEAT INNER BELT ASSEMBLY RH
71868T
9.REMOVE REAR SEAT INNER NO. 1 CUSHION SHIELD LH
10.REMOVE SEAT CUSHION COVER WITH PAD
73330H
11.REMOVE REAR SEAT LAP TYPE BELT ASSEMBLY RH
Remove the bolt and rear seat lap type belt assembly RH.
