RM35X0E _53 Suspension _078885 TIRE PRESSURE MONITORING _0388792 TIRE PRESSURE WARNING RECEIVER(for High Roof) A

TIRE PRESSURE MONITORING  TIRE PRESSURE WARNING RECEIVER(for High Roof)  REMOVAL


CAUTION / NOTICE / HINT

The necessary procedures (adjustment, calibration, initialization, or registration) that must be performed after parts are removed, installed, or replaced during the tire pressure warning receiver removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced
Replaced Part or Performed Procedure Necessary Procedure Effect/Inoperative Function when Necessary Procedure not Performed Link
Tire pressure warning ECU and receiver
·

Register transmitter ID

·

Initialize tire pressure warning system


·

When DTC detection conditions of "transmitter ID not received" DTC are met, TPWS indicator blinks for 1 minute, and then illuminates.

·

Tire pressure warning function


for Initialization:
(Click here)
for Registration:
(Click here)

PROCEDURE

Hide 89760C 8.REMOVE TIRE PRESSURE WARNING ECU AND RECEIVER

NOTICE:
·

Do not drop the tire pressure warning ECU and receiver, strike it with tools or subject it to impact.

·

If the tire pressure warning ECU and receiver is subjected to an impact, replace it with a new one.



a.
C413089C01
0,0 0,0 false
V100135

Bolt
V100136

Connector


Remove the 2 bolts.


b.

Detach the 2 guides to disconnect the tire pressure warning ECU and receiver.


c.

Disconnect the connector and remove the tire pressure warning ECU and receiver.
