LIGHTING (EXT)  SIDE TURN SIGNAL LIGHT ASSEMBLY  REMOVAL

w/ Panoramic View Monitor System:

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are installed, removed or replaced during the side turn signal light assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced (for HV Model)

Replaced Part or Performed Procedure	Necessary Procedures	Effect/Inoperative Function when Necessary Procedures are not Performed	Link
· Side television camera assembly LH (Including removal and installation) · Side television camera assembly RH (Including removal and installation)	Side television camera view adjustment	Panoramic view monitor system	(202304,999999,_56,_083082,_0586733,RM1000000029R9F,)

Necessary Procedures After Parts Removed/Installed/Replaced (for Gasoline Model)

Replaced Part or Performed Procedure	Necessary Procedures	Effect/Inoperative Function when Necessary Procedures are not Performed	Link
· Side television camera assembly LH (Including removal and installation) · Side television camera assembly RH (Including removal and installation)	Side television camera view adjustment	Panoramic view monitor system	(202304,999999,_56,_083082,_0586733,RM1000000029R9F,)

HINT:

·

Use the same procedure for the RH and LH sides.

·

The procedure listed below is for the LH side.
