M20C-FKS EMISSION CONTROL  FUEL TANK CAP  INSPECTION

2.438,1.26 2.604,1.5 2.604,1.5 2.844,1.5 true 2.865,1.406 3.115,1.615 0.25,0.208 10 false *a

*a

Gasket

Visually check that the fuel tank cap assembly and gasket are not deformed or damaged.

If the fuel tank cap assembly or gasket is deformed or damaged, replace it.

0.573,1.573 0.969,1.573 true 0.417,1.49 0.635,1.698 0.219,0.208 10 false *a

*a

ID Mark

Confirm that ID mark W is printed on the fuel tank cap assembly.

CAUTION:

Make sure to use a fuel tank cap assembly that has the correct ID mark, or a malfunction may occur in the fuel system.
