PARK ASSIST / MONITORING  TELEVISION CAMERA(for Side)  REMOVAL

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are removed and installed, or replaced during side television camera assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced

Replaced Part or Performed Procedure	Necessary Procedures	Effect/Inoperative Function When Necessary Procedures are not Performed	Link
*: Even when not replacing the part, it is necessary to perform the specified necessary procedures after installation.
· Side television camera assembly LH* · Side television camera assembly RH*	Side television camera view adjustment	Panoramic View Monitor System	(202409,999999,_56,_111825,_0500432,RM100000002O1F6,)
Replacement or removal and installation of 2 or more parts: · Front television camera assembly, Radiator grille sub-assembly or Front bumper assembly · Rear television camera assembly · Side television camera assembly LH or Outer rear view mirror assembly LH · Side television camera assembly RH or Outer rear view mirror assembly RH	Television camera view adjustment

HINT:

·

Use the same procedure for the RH side and LH side.

·

The following procedure is for the LH side.
