RM38N0EC
_56
Audio / Visual / Telematics
_111822
AUDIO / VIDEO
_0500663
NOISE FILTER
K
AUDIO / VIDEO NOISE FILTER COMPONENTS
ILLUSTRATION
| *A | for SFTM Made | *B | for Gasoline Model |
| *C | for HV Model | - | - |
| *1 | DECK BOARD ASSEMBLY | *2 | REAR SEAT CUSHION ASSEMBLY |
| *3 | REAR SEAT CUSHION LOCK HOOK | *4 | REAR SEAT HEADREST ASSEMBLY |
| *5 | REAR SEATBACK ASSEMBLY LH | *6 | Clip |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) | ● | Non-reusable part |
ILLUSTRATION
| *A | for GTMC Made | *B | for Gasoline Model |
| *C | for HV Model | - | - |
| *1 | DECK BOARD ASSEMBLY | *2 | REAR SEAT CUSHION ASSEMBLY |
| *3 | REAR SEAT CUSHION LOCK HOOK | *4 | REAR SEAT HEADREST ASSEMBLY |
| *5 | REAR SEATBACK ASSEMBLY LH | - | - |
|
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) | ● | Non-reusable part |
ILLUSTRATION
| *A | for SFTM Made | - | - |
| *1 | REAR FLOOR FINISH PLATE | *2 | REAR NO. 1 FLOOR MAT SUPPORT SIDE PLATE |
| *3 | REAR NO. 3 FLOOR BOARD | *4 | REAR SEATBACK BOARD CARPET ASSEMBLY RH |
| *5 | SPARE WHEEL COVER TRAY | *6 | Clip |
| ● | Non-reusable part | - | - |
ILLUSTRATION
| *A | for Gasoline Model | *B | for HV Model |
| *1 | CHILD RESTRAINT SEAT ANCHOR BRACKET SUB-ASSEMBLY LH | *2 | DECK TRIM SIDE PANEL ASSEMBLY LH |
| *3 | NO. 3 BATTERY SERVICE COVER BOARD | *4 | RADIO SETTING CONDENSER |
| *5 | REAR DOOR OPENING TRIM WEATHERSTRIP LH | *6 | REAR DOOR SCUFF PLATE LH |
| *7 | REAR SEAT SIDE GARNISH LH | *8 | REAR SEATBACK HINGE SUB-ASSEMBLY LH |
|
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping" : N*m (kgf*cm, ft.*lbf) |
|
N*m (kgf*cm, ft.*lbf): Specified torque |
| ● | Non-reusable part | - | - |
