RM38N0EC
_58
Vehicle Interior
_111839
SEAT
_0525818
POWER SEAT SWITCH(for GTMC Made)
K
SEAT POWER SEAT SWITCH(for GTMC Made) COMPONENTS
ILLUSTRATION
| *1 | FRONT SEAT CUSHION SHIELD | *2 | FRONT SEAT FRONT CUSHION SHIELD |
ILLUSTRATION
| *A | for Driver Side | *B | for Front Passenger Side |
| *1 | FRONT POWER SEAT SWITCH | *2 | FRONT SEAT CUSHION SHIELD |
| *3 | RECLINING POWER SEAT SWITCH KNOB | *4 | SEAT ADJUSTER SHIELD CLAMP BRACKET |
| *5 | SLIDE AND VERTICAL POWER SEAT SWITCH KNOB | - | - |
