AXLE AND DIFFERENTIAL
_0525514
REAR DIFFERENTIAL CARRIER ASSEMBLY
K
AXLE AND DIFFERENTIAL REAR DIFFERENTIAL CARRIER ASSEMBLY COMPONENTS
ILLUSTRATION
| *1 | NO. 2 FUEL TANK PROTECTOR | *2 | TAIL EXHAUST PIPE ASSEMBLY |
| *3 | GASKET | - | - |
|
N*m (kgf*cm, ft.*lbf): Specified torque | ● | Non-reusable part |
ILLUSTRATION
| *1 | REAR DIFFERENTIAL CARRIER ASSEMBLY | *2 | WIRE HARNESS CLAMP BRACKET |
| *3 | REAR UPPER DIFFERENTIAL MOUNT STOPPER | *4 | REAR LOWER DIFFERENTIAL MOUNT STOPPER |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) |
|
N*m (kgf*cm, ft.*lbf): Specified torque |
| ● | Non-reusable part | - | - |
ILLUSTRATION
| *1 | REAR DIFFERENTIAL CARRIER SUB-ASSEMBLY | *2 | REAR DIFFERENTIAL SUPPORT |
| *3 | REAR NO. 1 DIFFERENTIAL SUPPORT | *4 | REAR NO. 2 DIFFERENTIAL SUPPORT |
|
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) | ● | Non-reusable part |
|
Do not apply lubricants to the threaded parts | - | - |
ILLUSTRATION
| *1 | DIAPHRAGM OIL SEAL | *2 | REAR DIFFERENTIAL CARRIER COVER BREATHER PLUG |
| *3 | REAR DIFFERENTIAL CARRIER COVER PLUG | *4 | REAR DIFFERENTIAL FILLER PLUG |
| *5 | REAR DRIVE SHAFT OIL SEAL LH | *6 | REAR DRIVE SHAFT OIL SEAL RH |
| *7 | REAR DRIVE PINION FRONT TAPERED ROLLER BEARING | *8 | REAR DRIVE PINION NUT |
| *9 | STUD BOLT | *10 | TRANSMISSION COUPLING ASSEMBLY |
| *11 | TRANSMISSION COUPLING CONICAL SPRING WASHER | *12 | TRANSMISSION COUPLING SHIM |
| *13 | 4WD LINEAR SOLENOID | *14 | YOKE |
| *15 | SNAP RING | *16 | O-RING |
| *17 | GASKET | *18 | REAR DIFFERENTIAL DRAIN PLUG |
|
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) |
|
N*m (kgf*cm, ft.*lbf): Specified torque |
| * | For use with SST | ● | Non-reusable part |
|
MP grease |
|
When reusing part: Hypoid gear oil LSD |
| ★ | Precoated part | - | - |
| *T1 | For use without SST: 245 N*m (2498 kgf*cm, 181 ft.*lbf) or less
For use with SST: 226 N*m (2305 kgf*cm, 167 ft.*lbf) or less |
- | - |
ILLUSTRATION
| *1 | DIFFERENTIAL DRIVE PINION | *2 | DIFFERENTIAL RING GEAR |
| *3 | DIFFERENTIAL SIDE BEARING RETAINER | *4 | REAR DIFFERENTIAL BREATHER PLUG OIL DEFLECTOR |
| *5 | REAR DIFFERENTIAL CASE SUB-ASSEMBLY | *6 | REAR DIFFERENTIAL DRIVE PINION BEARING SPACER |
| *7 | REAR DRIVE PINION REAR BEARING | *8 | STRAIGHT PIN |
| *9 | REAR DIFFERENTIAL CARRIER SUB-ASSEMBLY | *10 | REAR DIFFERENTIAL CASE BEARING LH |
| *11 | REAR DIFFERENTIAL CASE BEARING RH | *12 | REAR DIFFERENTIAL DRIVE PINION WASHER |
| *13 | REAR DIFFERENTIAL CASE BOLT | *14 | REAR DIFFERENTIAL SIDE GEAR SHAFT WASHER |
|
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) |
|
N*m (kgf*cm, ft.*lbf): Specified torque |
| ● | Non-reusable part |
|
Do not apply lubricants to the threaded parts |
