Drivetrain
_111807
DRIVE SHAFT / PROPELLER SHAFT
_0525508
PROPELLER SHAFT ASSEMBLY
K
DRIVE SHAFT / PROPELLER SHAFT PROPELLER SHAFT ASSEMBLY COMPONENTS
ILLUSTRATION
| *1 | FRONT FLOOR COVER LH | *2 | NO. 2 FLOOR UNDER COVER |
| *3 | FRONT FLOOR COVER RH | *4 | NO. 1 FLOOR UNDER COVER |
|
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
ILLUSTRATION
| *1 | LOWER NO. 1 FRONT FLOOR HEAT INSULATOR | - | - |
|
|
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
ILLUSTRATION
| *1 | PROPELLER SHAFT WITH CENTER BEARING ASSEMBLY | *2 | CENTER NO. 2 SUPPORT BEARING WASHER |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) |
|
Do not apply lubricants to the threaded parts |
