GF1A TRANSFER OIL
K
MAINTENANCE GF1A TRANSFER OIL COMPONENTS
ILLUSTRATION
| *1 | FRONT FENDER FRONT SPLASH SHIELD LH | *2 | FRONT FENDER FRONT SPLASH SHIELD RH |
| *3 | NO. 1 ENGINE UNDER COVER | *4 | NO. 2 ENGINE UNDER COVER ASSEMBLY |
|
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
ILLUSTRATION
| *1 | TRANSFER FILLER PLUG | *2 | TRANSFER DRAIN PLUG |
| *3 | GASKET | - | - |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) | * | For use with union nut wrench |
| ● | Non-reusable part | - | - |
