RM38N0EC
_52
Drivetrain
_119335
GF1A TRANSFER / 4WD / AWD
_0524096
4WD CONTROL ECU
K
GF1A TRANSFER / 4WD / AWD 4WD CONTROL ECU COMPONENTS
ILLUSTRATION
| *1 | REAR NO. 3 FLOOR BOARD | *2 | SPARE WHEEL COVER TRAY |
| *3 | REAR FLOOR FINISH PLATE | *4 | REAR NO. 1 FLOOR MAT SUPPORT SIDE PLATE |
| *5 | REAR DOOR SCUFF PLATE LH | *6 | REAR DOOR OPENING TRIM WEATHERSTRIP LH |
| *7 | REAR SEATBACK HINGE SUB-ASSEMBLY LH | *8 | REAR SEAT SIDE GARNISH LH |
| *9 | DECK TRIM SIDE PANEL ASSEMBLY LH | - | - |
|
Tightening torque for "Major areas involving basic vehicle performance such as moving/turning/stopping": N*m (kgf*cm, ft.*lbf) | - | - |
ILLUSTRATION
| *1 | 4WD ECU ASSEMBLY | - | - |
|
N*m (kgf*cm, ft.*lbf): Specified torque | - | - |
