SEAT  SEAT HEATER SYSTEM  PARTS LOCATION

ILLUSTRATION

5.26,3.729 5.031,3.729 5.031,3.729 3.604,2.854 false 2.417,2.052 2.417,0.75 2.417,0.75 2.083,0.75 false 5.333,3.646 5.833,3.833 0.5,0.188 10 false *1 (*A) 1.625,0.667 2.198,0.875 0.573,0.208 10 false *3 (*B) 5.344,3.906 5.844,4.094 0.5,0.188 10 false *2 (*B)

*A	for NR Series Engine	*B	except NR Series Engine
*1	NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - S/HTR F/L FUSE - S/HTR F/R FUSE	*2	NO. 1 ENGINE ROOM RELAY BLOCK AND NO. 1 JUNCTION BLOCK ASSEMBLY - S/HTR F/L FUSE - S/HTR F/R FUSE - ECU-IGP NO. 3 FUSE - S/HTR-MAIN FUSE
*3	NO. 2 RELAY BLOCK ASSEMBLY - S-HTR Relay	-	-

ILLUSTRATION

1.177,2.552 1.594,2.552 false 3.677,2.458 3.677,0.531 3.677,0.531 3.896,0.531 false 3.375,2.542 3.375,0.542 3.375,0.542 3.177,0.542 false 3,0.438 3.313,0.594 0.313,0.156 10 false *1 3.938,0.427 4.25,0.583 0.313,0.156 10 false *2 0.729,2.458 1.271,2.625 0.542,0.167 10 false *3 (*A) 0.729,2.677 1.323,2.875 0.594,0.198 10 false *4 (*B)

*A	for NR Series Engine	*B	except NR Series Engine
*1	SEAT HEATER SWITCH (for LH)	*2	SEAT HEATER SWITCH (for RH)
*3	DRIVER SIDE JUNCTION BLOCK ASSEMBLY - PANEL FUSE	*4	POWER DISTRIBUTION BOX ASSEMBLY - PANEL FUSE

ILLUSTRATION

2.229,4.323 2.479,4.323 2.479,4.323 2.479,2.906 false 3.302,4.542 3.552,4.542 3.552,4.542 3.552,3.542 false 3.323,1.344 3.323,0.344 3.323,0.344 3.573,0.344 false 4.396,1.958 4.396,0.958 4.396,0.958 4.646,0.958 false 3.135,4.458 3.448,4.615 0.313,0.156 10 false *1 2.063,4.24 2.375,4.396 0.313,0.156 10 false *2 4.74,0.875 5.052,1.031 0.313,0.156 10 false *3 3.656,0.26 3.969,0.417 0.313,0.156 10 false *4

*1	FRONT SEAT CUSHION HEATER (SEPARATE TYPE FRONT SEAT CUSHION COVER LH)	*2	FRONT SEAT CUSHION HEATER (SEPARATE TYPE FRONT SEAT CUSHION COVER RH)
*3	FRONT SEATBACK HEATER (SEPARATE TYPE FRONT SEATBACK COVER LH)	*4	FRONT SEATBACK HEATER RH (SEPARATE TYPE FRONT SEATBACK COVER RH)
