LIGHTING (EXT)  SIDE TURN SIGNAL LIGHT ASSEMBLY(for Outer Rear View Mirror)  REMOVAL

w/ Panoramic view monitor system:

The necessary procedures (adjustment, calibration, initialization or registration) that must be performed after parts are installed, removed or replaced during side turn signal light assembly removal/installation are shown below.

Necessary Procedures After Parts Removed/Installed/Replaced

Replacement Part or Procedure	Necessary Procedures	Effects/Inoperative Functions when not Performed	Link
· Side television camera assembly LH (Including removal and installation) · Side television camera assembly RH (Including removal and installation)	Side television camera view adjustment	Panoramic view monitor system	(201906,202310,_56,_079315,_0396274,RM100000001IGR4,202310,999999,_56,_079315,_0396274,RM100000002G5L7,)
· Side television camera assembly LH or outer rear view mirror assembly LH · Side television camera assembly RH or outer rear view mirror assembly RH	Television camera view adjustment (Adjustment of all cameras) HINT: Replacement or removal and installation of 2 or more parts

HINT:

·

Use the same procedure for the RH and LH sides.

·

The procedure described below is for the LH side.
