TIRE PRESSURE MONITORING  TIRE PRESSURE WARNING SYSTEM  FAIL-SAFE CHART


FAIL-SAFE FUNCTION


a.

When a malfunction occurs in the tire pressure warning system, the tire pressure warning light illuminates after blinking for 1 minute to inform the driver of the system failure.


b.

As a result of this, tire pressure monitoring is disabled and a DTC is stored in the tire pressure warning ECU and receiver.


c.
C418309

w/ Tire Inflation Display Function:

When there is a system malfunction, the output display according to the tire position turns off.
