7GR-FKS LUBRICATION  OIL PRESSURE SWITCH  COMPONENTS

ILLUSTRATION

3.271,7.375 4.26,7.563 0.99,0.188 5.719,7.031 6.708,7.219 0.99,0.188 1.167,4.875 1.875,5.063 0.708,0.188 2.615,6.719 2.917,6.719 2.917,6.719 3.146,6.292 false 1.885,4.969 2.167,4.969 2.167,4.969 2.417,4.625 false 5.323,7.125 5.708,7.125 false 3.771,7.365 3.771,7.198 false 1.177,5.083 1.406,5.281 0.229,0.198 10 false *1 2.417,6.625 2.625,6.823 0.208,0.198 10 false *2 0.979,4.885 1.135,5.042 0.156,0.156 10 false ★ 3.875,7.01 4.146,7.208 0.271,0.198 10 false x 4 4.573,7.167 5.167,7.385 0.594,0.219 10 false x 16 (*a) 5.344,7.146 5.615,7.344 0.271,0.198 10 false x 2 3.313,7.385 4.302,7.573 0.99,0.188 8 false 7.5 (76, 66 in.*lbf) 5.76,7.052 6.75,7.24 0.99,0.188 8 false 5.5 (56, 49 in.*lbf) 1.198,4.885 1.917,5.073 0.719,0.188 8 false 15 (153, 11) 4.573,7.375 5.167,7.594 0.594,0.219 10 false x 14 (*b)

*1	ENGINE OIL PRESSURE SWITCH ASSEMBLY	*2	NO. 1 ENGINE UNDER COVER SUB-ASSEMBLY
*a	w/ No. 2 Engine Under Cover Sub-assembly	*b	w/o No. 2 Engine Under Cover Sub-assembly
	N*m (kgf*cm, ft.*lbf): Specified torque		Adhesive 1344
★	Precoated part	-	-
