ENGINE HOOD COURTESY SWITCH
A
THEFT DETERRENT / KEYLESS ENTRY ENGINE HOOD COURTESY SWITCH REMOVAL
CAUTION / NOTICE / HINT
COMPONENTS (REMOVAL)
2.115,1.958 2.448,1.958
false
0.885,1.115 1.219,1.115
false
2.729,0.875 3.063,0.875
false
0.646,0.958 0.927,1.313
0.281,0.354
18
false
1
1.667,2.177 1.979,2.375
0.313,0.198
10
false
x3
3.146,0.719 3.427,1.073
0.281,0.354
18
false
2
2.531,1.823 2.813,2.177
0.281,0.354
18
false
3
1.573,0.458 1.854,0.813
0.281,0.354
10
false
x2
2.25,0.24 2.531,0.51
0.281,0.271
10
false
x4
| Procedure | Part Name Code |
|
|
|
|
|---|---|---|---|---|---|
| 1 | NO. 1 RADIATOR TO SUPPORT SEAL | 16561C | - | - | - |
| 2 | INLET NO. 1 AIR CLEANER | 17751 | - | - | - |
| 3 | HOOD LOCK ASSEMBLY WITH COURTESY LIGHT SWITCH | 53510G | - | - | - |
PROCEDURE
16561C
1.REMOVE NO. 1 RADIATOR TO SUPPORT SEAL
17751
2.REMOVE INLET NO. 1 AIR CLEANER
53510G
3.REMOVE HOOD LOCK ASSEMBLY WITH COURTESY LIGHT SWITCH
a.
